Reservoir:

1、容積尺寸：L420×W310×H400mm，配置封閉蓋，外貼保溫棉，SUS304材料制作。

1. Volume size: L420 × W310 × H400mm, equipped with closed cover, externally pasted with thermal insulation cotton, made of SUS304 material.

2、箱內設置不銹鋼液位控制，無液自動關閉循環泵并聲光報警。

2. Stainless steel liquid level control is set in the tank, and the circulating pump will be automatically shut down and give an audible and visual alarm when there is no liquid.

3、設進水口，外接水源。

3. The water inlet is set and connected to the water source.

4、儲液箱底部向排液方向傾斜，排水口徑為1"。

4. The bottom of the liquid storage tank is inclined towards the drainage direction, and the drainage diameter is 1 ".

5、儲液箱設有缸蓋系統，蓋板采用嵌入式結構，以防洗劑泡沫溢出。

5. The fluid storage tank is equipped with a cylinder head system, and the cover plate adopts an embedded structure to prevent the overflow of detergent foam.

加熱：內置不銹鋼加熱管家熱，加熱功率4KW。

Heating: built-in stainless steel heating pipe, heating power 4KW.

溫控器：數顯式溫度自動控制系統，測、控清洗槽內溫度。工作溫度可調。

Temperature controller: digital display temperature automatic control system, measuring and controlling the temperature in the cleaning tank. The working temperature is adjustable.

超純水高頻漂洗槽：

Ultra pure water high-frequency rinsing tank:

1、結構為鋸齒形三面溢流，第13、12槽設進純水口，與純水預熱箱及純水源并聯相接。溢水槽寬35mm。通過溢流可以源源不斷進入新鮮液體，保持槽內液體有較高的清潔度，進水前加設3道PP過濾系統，過濾精度根據生產需要設定。

1. The structure is zigzag three side overflow. The 13th and 12th grooves are equipped with pure water inlet, which is connected in parallel with pure water preheating tank and pure water source. The overflow channel is 35mm wide. Fresh liquid can enter the tank continuously through overflow to keep the liquid in the tank clean. Three PP filtering systems are added before the water enters the tank. The filtering accuracy is set according to the production needs.

2、槽體設排液口，可通過手動球閥將液體直接排掉。

2. The tank body is provided with a drain port, which can drain the liquid directly through a manual ball valve.

3、每一清洗槽外貼2KW鑄鋁加熱板。

3. Each cleaning tank is pasted with a 2KW cast aluminum heating plate.

4、清洗槽外貼保溫棉。

4. The cleaning tank is pasted with thermal insulation cotton.

四、拋動機構：

4、 Throwing mechanism:

形式：

Form:

1、平面連桿機構驅動，帶動清洗籃在清洗槽內作上下運動。運行穩定性好，噪聲小。

1. The planar linkage mechanism drives the cleaning basket to move up and down in the cleaning tank. Good operation stability and low noise.

2、拋動托架為不銹鋼材質，拋動架根部要加強，防止斷裂。

2. The throwing bracket is made of stainless steel, and the root of the throwing bracket shall be strengthened to prevent fracture.
